Oil Gas Hot Air Generator | Hot Air Heater Boiler

It is widely used in industries such as grain, fertilizer, chemical, printing and dyeing, vegetable dehydration, residue drying and mine heating.

Direct type & Indirect type Hot Air Furnace

1. Direct type gas hot air furnace

It is to use fuel to burn directly, to form hot air after high purification treatment, and to directly contact with the material to heat and dry or bake. The high-temperature combustion gas obtained after the combustion reaction of the fuel is further contacted with the outside air, mixed to a certain temperature, and directly enters the drying room or baking room, where it contacts with the material to be dried, heats and evaporates moisture, thereby obtaining a dry product.

2. Indirect type gas hot air furnace

It is mainly suitable for drying materials that are not allowed to be contaminated, or drying of heat-sensitive materials with low temperature. Such as: milk powder, pharmaceuticals, synthetic resins, fine chemicals, etc. This kind of heating device uses steam, heat transfer oil, flue gas, etc. as the carrier to heat the air through various forms of heat exchangers. The most essential problem of indirect hot blast stove is heat exchange. The larger the heat exchange area, the higher the heat transfer rate, the better the energy saving effect of the hot blast stove, and the longer the life of the furnace body and heat exchanger. Conversely, the size of the heat exchange area can also be identified from the flue gas temperature. The lower the smoke temperature, the higher the heat transfer rate and the larger the heat exchange area.

Request A Quote Now

Industrial reciprocating grate hot air generator is customized according to specific biomass fuel, heat output, hot air temperature, temperature control accuracy, etc.

Before we send a quotation for your request, we need some informations as following:

1. what biomass fuel you want to burn (fuel size, moisture content, calorific value, etc.)

2. what's the required thermal capacity kcal/hour

3. What's the required hot air temperature

4. What's the required temperature control accuracy

5. What will the hot air be used for

Why Choose Us ?

1. We offer all kinds of boiler machine, customized service for customers' demand, send your specific details to us.

2. 60+Years' experience in boiler design, technique, production, installation and operation. 10+Years export boiler experience.

3. Global service team for boiler solution, boiler design, order contract, boiler delivery, boiler install and commissioning.

Global Boiler Service

1. Offer catalogue, various boiler model for choose, inquire one you prefer.

2. Technical discussion on boiler system solution for your company use.

3. Warmly welcome all customers come to visit the production base

4. Trustable after sale service, for boiler installation, training operators.

5. Whole life service for boiler consult, contact us whenever.

6. Yuanda products have covered all provinces and cities of China and have been exported to 90 countries and regions such as Bangladesh, Nigeria, Chile, Russia, etc. More than 8000+ boiler projects worldwide !
