Bakery Steam Generators & Steam Boilers For Commercial Bakeries Oven
- Steam Generator Boiler:35kg/hour-50000kg/hour
- Fuel/Power:Electricity, Diesel, Gas, Lpg, Waste oil, Wood, Biomass Pellets, Coal
- Steam Supply For Bakery Oven:100°C-450°C
- Manufacture Code:ISO, CE, ASME, DOSH, EAC
- Inquiry Email:shirley@yuanda-boiler.com
Steam Generator & Steam Boiler For Bakery Oven
Yuanda Boiler manufacture STEAM GENERATOR & STEAM BOILER for a variety of commercial baking equipment applications, such as, proof boxes, ovens, & other food and bakery equipment.
Heat Power: 24kw-7000kw
Steam Capacity: 35kg-10000kg/hour
Operating Steam Pressure Range:1bar-20bars
Choose The Suitable Boiler
Most popular boilers including Diesel Boiler, Lpg Gas Boiler, Electric Boiler, Low Cost Wood Biomass Boiler.
Structure: fire tube structure boiler, water tube structure boiler
Types: vertical boiler, horizontal boiler (if boiler room space limited, you can choose Vertical Boiler.)
||| Most Popular: Industrial Fuel Oil Diesel Lpg Gas Boiler |||
||| New Trend: Electrical Hot Water Steam Generator Boiler |||
||| Economic Small Wood Boiler Biomass Boiler Coal Boiler |||
Catalogue All Products
1. Gas boiler, Lpg boiler, Diesel boiler, Heavy oil boiler, Dual fuel boiler, Exhaust gas waste heat recovery boiler
2. Coal boiler, Charcoal boiler, Wood boiler, Biomass boiler, Pellet boiler, Ricehusk boiler, Palm shells boiler
3. Electric boiler, Electric steam generator, Electric hot water boiler,
4. Thermal Oil Heater Boiler, Thermic Fluid Heater, Hot Oil Boiler. (Powered by gas, diesel, electric, coal, wood biomass)
5. Steam Boiler, Hot Water Boiler, Steam Generator Boiler, Combined Heat and Power Boiler, Superheated Steam Boiler
About us Yuanda Boiler
1. Qualified by ASME, CE, ISO, EAC, DOSH, TUV, BUV, Ensuring High Quality and Compliance with International Standards.
2. Our company established since 1956, over 65 years manufactureing experiences, 15 Years export experience.
3. Global service team for boiler solution, boiler design, order contract, boiler delivery, boiler install and commissioning.
4. Until now, our products have been exported to 132 countries all over the world, trustable quality & services for lifespan.
Gas Oil Fired Steam Boiler Technical Parameter | ||||||||
---|---|---|---|---|---|---|---|---|
Model | Rated capacity(t/h) | Rated pressure (Mpa) | Rated temperature(℃) | feed temperature(℃) | Thermal efficiency(%) | Fuel comsumption | max transportation weigh(t) | |
light diesel oil(kg/h) | natural gas(Nm³/h) | |||||||
WNS0.5 | 0.5 | 0.1mpa-3.8mpa | 100°C-450°C | 20°C/104°C | >98 | 32.5 | 35.7 | 3.5 |
WNS1 | 1 | >98 | 64.5 | 70.1 | 5.5 | |||
WNS2 | 2 | >98 | 129.3 | 140.3 | 8 | |||
WNS3 | 3 | >98 | 192.9 | 212.1 | 10.7 | |||
WNS4 | 4 | >98 | 258.2 | 283.4 | 11.6 | |||
WNS6 | 6 | >98 | 388.6 | 424.2 | 17.5 | |||
WNS8 | 8 | >98 | 514.6 | 566.3 | 22.5 | |||
WNS10 | 10 | >98 | 641.7 | 707.8 | 26.8 | |||
WNS15 | 15 | >98 | 960.1 | 1061.7 | 35.2 | |||
WNS20 | 20 | >98 | 1276.2 | 1415.8 | 45.5 | |||
SZS10 | 10 | >98 | 618 | 660 | 36 | |||
SZS15 | 15 | >98 | 927 | 987 | 45 | |||
SZS20 | 20 | >98 | 1256 | 1316 | 52.6 | |||
SZS25 | 25 | >98 | 1545 | 1660 | 55.3 | |||
SZS30 | 30 | >98 | 1856 | 1981 | 63.7 | |||
SZS40 | 40 | >98 | 2470 | 2630 | 77.4 | |||
Note: Parameter is for reference only, if any changes should follow the factory technical data. |
